ЖКИ 213
| Параметр ЖКИ | Значение |
|---|---|
| Порядковый номер | 213 |
| Паспорт | 213ps.pdf |
| Знакогенератор | cgrom.pdf |
| Количество знаков | 2x20р.(5x8); Ucc.=2,7-5,5 В |
| Мультиплексность | 16 |
| Высота основных цифр, мм | 10 |
| Ширина индикатора, мм | 162 |
| Высота индикатора, мм | 46 |
| Ширина рабочей поверхности, мм | 147 |
| Высота рабочей поверхности, мм | 26 |
| Тип драйвера | s6a0069 |
| Исполнение | Tmin, ºC | Tmax, ºC | Ucc, В |
|---|---|---|---|
| СА213Тх16хх1 | -10 | 55 | 2.7÷5.5 |
| CA213Tx16xx4 | -40 | 55 | 2.7÷5.5 |
| CA213Tx16xx6 | -10 | 70 | 2.7÷5.5 |
| CA213Tx16xx7 | -20 | 70 | 2.7÷5.5 |
| CA213Tx16xx9 | -40 | 70 | 2.7÷5.5 |
| CF213Tx16xx1 | -10 | 55 | 2.7÷5.5 |
| CF213Tx16xx2 | -20 | 55 | 2.7÷5.5 |
| CF213Tx16xx4 | -40 | 55 | 2.7÷5.5 |
| CF213Tx16xx6 | -10 | 70 | 2.7÷5.5 |
| CF213Tx16xx7 | -20 | 70 | 2.7÷5.5 |
| CF213Tx16xx9 | -40 | 70 | 2.7÷5.5 |
| CS213Tx16xx1 | -10 | 55 | 2.7÷5.5 |
| CS213Tx16xx2 | -20 | 55 | 2.7÷5.5 |
| CS213Tx16xx4 | -40 | 55 | 2.7÷5.5 |
| CS213Tx16xx6 | -10 | 70 | 2.7÷5.5 |
| CS213Tx16xx7 | -20 | 70 | 2.7÷5.5 |
| CS213Tx16xx9 | -40 | 70 | 2.7÷5.5 |
| KA213Tx16xx1 | -10 | 55 | 2.7÷5.5 |
| KA213Tx16xx1-Dx | -10 | 55 | 2.7÷5.5 |
| KA213Tx16xx2 | -20 | 55 | 2.7÷5.5 |
| KA213Tx16xx2-Dx | -20 | 55 | 2.7÷5.5 |
| KA213Tx16xx4 | -40 | 55 | 2.7÷5.5 |
| KA213Tx16xx4-Dx | -40 | 55 | 2.7÷5.5 |
| KF213Tx16xx1 | -10 | 55 | 2.7÷5.5 |
| KF213Tx16xx1-Dx | -10 | 55 | 2.7÷5.5 |
| KF213Tx16xx2 | -20 | 55 | 2.7÷5.5 |
| KF213Tx16xx2-Dx | -20 | 55 | 2.7÷5.5 |
| KF213Tx16xx4 | -40 | 55 | 2.7÷5.5 |
| KF213Tx16xx4-Dx | -40 | 55 | 2.7÷5.5 |
| KF213Tx16xx6 | -10 | 70 | 2.7÷5.5 |
| KF213Tx1xx6-Dx | -10 | 70 | 2.7÷5.5 |
| KF213Tx16xx7 | -20 | 70 | 2.7÷5.5 |
| KF213Tx16xx7-Dx | -20 | 70 | 2.7÷5.5 |
| KF213Tx16xx9 | -40 | 70 | 2.7÷5.5 |
| KF213Tx16xx9-Dx | -40 | 70 | 2.7÷5.5 |
| KA213Tx16xx6 | -10 | 70 | 2.7÷5.5 |
| KA213Tx16xx6-Dx | -10 | 70 | 2.7÷5.5 |
| KA213Tx16xx7 | -20 | 70 | 2.7÷5.5 |
| KA213Tx16xx7-Dx | -20 | 70 | 2.7÷5.5 |
| KA213Tx16xx9 | -40 | 70 | 2.7÷5.5 |
| KA213Tx16xx9-Dx | -40 | 70 | 2.7÷5.5 |
| KS213Tx16xx1 | -10 | 55 | 2.7÷5.5 |
| KS213Tx16xx1-Dx | -10 | 55 | 2.7÷5.5 |
| KS213Tx16xx2 | -20 | 55 | 2.7÷5.5 |
| KS213Tx16xx2-Dx | -20 | 55 | 2.7÷5.5 |
| KS213Tx16xx4 | -40 | 55 | 2.7÷5.5 |
| KS213Tx16xx4-Dx | -40 | 55 | 2.7÷5.5 |
| KS213Tx16xx6 | -10 | 70 | 2.7÷5.5 |
| KS213Tx16xx6-Dx | -10 | 70 | 2.7÷5.5 |
| KS213Tx16xx7 | -20 | 70 | 2.7÷5.5 |
| KS213Tx16xx7-Dx | -20 | 70 | 2.7÷5.5 |
| KS213Tx16xx9 | -40 | 70 | 2.7÷5.5 |
| KS213Tx16xx9-Dx | -40 | 70 | 2.7÷5.5 |
| CA213Tx16xx2 | -20 | 55 | 2.7÷5.5 |
